Macnaught Oil Dispensing System 3:1 - R-SERIES Pump - No Gun OS100B-01
Available
The Macnaught OS100B-01 is a trolley oil dispensing system for 205 L oil drums, built for workshops and dealerships. The pump and hose reel come on a TR205 drum trolley, so you can move it to the job and pump oil straight from the drum. It is a drum trolley system, not an IBC system.
In the system: a TR205 drum trolley, a Retracta oil hose reel with 1/2" x 15m of hose, an R300S-01 air-operated pump, and all necessary fittings and hoses. No oil control gun is included. The pump is a 3:1 R-Series pump. R-series pumps have a heavy-duty aluminium and steel air motor with large exhaust ports to prevent icing. The ratio is how much the pump multiplies your air pressure at the oil outlet. A higher ratio gives more push for long hose runs and thick oil, but usually less oil per minute. A lower ratio usually moves more oil with less push. At 3:1 the R300S-01 has a free flow of up to 23 L/min and is rated for oils up to SAE140, coolants, kerosene and diesel.
Where this product is used
- Dispensing oil from a 205 L drum in a workshop or dealership
- Moving oil dispensing around the workshop on a drum trolley
- Pumping oils up to SAE140, coolants, kerosene and diesel
Features
- Trolley-based system for 205 L oil drums. It suits either 205 litre or 180kg drums
- Includes a TR205 drum trolley
- Includes a Retracta oil hose reel with 1/2" x 15m hose
- Includes an R300S-01 3:1 air-operated pump
- Pump free flow of up to 23 L/min, or 23 / 19 / 18 L/min at SAE10 / SAE15W-40 / SAE90
- Includes all necessary fittings and hoses
- No oil control gun is included
- Manual cautions: apply the wheel brake when parked, secure the drum with the safety chain and disconnect the air before moving the trolley
- How to choose: OS100B-01 has no gun, OS100G-01 has an unmetered gun and OS100GE-01 has a metered gun
Key specifications
| Specification | Detail |
|---|---|
| Brand | Macnaught |
| Model | OS100B-01 |
| Part number | OS100B-01 |
| Type | Trolley-based oil dispensing system for 205 L drums, no gun |
| Pump | R300S-01 3:1 R-Series air-operated pump |
| Pump free flow | Up to 23 L/min |
| Hose reel | Retracta oil hose reel, 1/2" x 15m hose |
| Trolley | TR205 drum trolley |
| Gun | None (no gun) |
| Drum size | 205 litre or 180kg drums |
| Maximum air pressure | 10 bar (1000 kPa, 145 psi) |
| Suitable fluids (pump) | Oils to SAE140, coolants, kerosene, diesel |
Related Macnaught products
- Macnaught Oil Dispensing System 3:1 - R-SERIES Pump - No Gun OS500B-01: Other size or version
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Macnaught Oil Dispensing System 3:1 - R-SERIES Pump - No Gun OS100B-01
SKU: A0082811 | Model: OS100B-01
The OS100B-01 is Macnaught's drum trolley oil system with no gun. It includes a TR205 drum trolley, a Retracta oil hose reel with 1/2" x 15m hose, an R300S-01 3:1 pump and all necessary fittings and hoses. It suits 205 litre or 180kg drums.
