Timken Farmline Insert Bearing Cylindrical 12 x 32 x 16.66mm - 201KTT

Timken Farmline Insert Bearings (cylindrical outer ring) are locking-collar insert bearings that fit directly into a bored housing, combining the bearing and shaft-locking mechanism in one unit for straightforward fitting and replacement. Timken is a US-founded bearing manufacturer, supplied by AIMS Industrial to engineering, manufacturing and maintenance operations across Australia.

Where this product is used

Timken Farmline Insert Bearings are used in mounted bearing applications where the housing is bored to a straight diameter to suit the cylindrical outer ring.

• Replacing worn insert bearings in mounted units
• Housings bored to a matching straight diameter
• Shafts located by a locking collar rather than a pressed fit

Key specifications

Selecting the right option

Match the bore, O.D. and width first, then choose the seal type. Felt seals (TT) are contact seals for moderate speeds, R-Seals (R, RR) are positive contact rubber seals made for farm machinery, Mechani-Seals (L, LL) are frictionless labyrinth seals, and shields (D, DD) are non-contact. A G in the model code means a snap ring groove. Two sizes come in more than one seal: 30 x 62 x 16mm (two shields with snap ring, or two R-Seals) and 35 x 72 x 25mm (two felt seals, or two seals YY). Bore, O.D. and width are shown in millimetres as published by Timken.
