BECO shielded kiln black bearing: 6 sizes 6001BHTS.320C_BECO

This is the BECO Extreme Temperature Deep Groove Ball Bearing, Open Kiln Black 320°C.

The BECO open kiln black range is a deep groove ball bearing built for high temperature service in kilns, ovens and furnaces. It has a kiln black finish, no seals or shields, so it is open on both sides, and is built on standard bearing boundary dimensions. This range has 6 sizes with bores from 12 to 55mm across the 6000, 6200 and 6300 series.

Each size carries its own temperature rating: 270°C to 320°C or up to 320°C. The rating for each size is shown in the size table and in the specification for that size, so check it against your duty cycle when you select.

Where this product is used

• Kiln trolleys and brick kiln running gear
• Ovens
• Furnaces
• Other high temperature plant where an open bearing is specified

Features

• Temperature rating for each size, from 270°C to 320°C
• Open design with no seals or shields
• Kiln black finish
• Standard boundary dimensions, so it replaces a conventional bearing of the same size without rework
• 6 sizes across the 6000, 6200 and 6300 series, from 12 to 55mm bore

Key specifications

Available sizes

Fitting and use

Press the ring that has the interference fit onto its seat, and never push through the balls or the other ring.

Choosing the right option

Select by bore, outside diameter and width.

The temperature rating differs by size, so the rating for the size you select is the one that applies. Check it against your duty cycle.

This bearing is open on both sides, so there is no seal or shield to hold lubricant in or keep dust out. Factor that into your lubrication and maintenance plan.

Also available from BECO: the shielded 280°C range, the graphite cage 350°C range, the open 330°C range.

Product details
