Dixon SS2P-MF-08MM 1/4" (8 mm) Two-Piece Ball Valve 316 SS BSP F x M
Out of stock
This Dixon two-piece ball valve has a 316 stainless steel body (ASTM A351 CF8M), a full-bore passage, a locking device and male x female BSP ends. Dixon lists it in 8 sizes, from 1/4" to 2" (manufacturer-stated).
Dixon rates the range at 1000 PSI CWP for water, oil and gas, and for fluids that are compatible with the body and trim, and lists AGA and Watermark approvals (manufacturer-stated). Check the approval you need against the product marking before you specify it.
Where this product is used
- Isolating air, water, oil and gas lines, and most chemical lines where the body and trim materials are compatible (manufacturer-stated).
- Pipework that needs the male x female end pattern: the male end screws into a female port and the female end takes a male nipple.
- Lines that need a lockable valve, because the design includes a locking device (manufacturer-stated).
Features
- Two-piece, full-bore design with a locking device (manufacturer-stated)
- Body: 316 stainless steel (ASTM A351 CF8M) (manufacturer-stated)
- End connection: male x female BSP (manufacturer-stated)
- Working pressure: 1000 PSI CWP for water, oil and gas, and for fluids compatible with body and trim (manufacturer-stated)
- Approvals listed by Dixon: AGA and Watermark (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Body material | 316 stainless steel (ASTM A351 CF8M) |
| Design | Two-piece, full bore, locking device |
| End connection | Male x female BSP |
| Working pressure | 1000 PSI CWP |
| Approvals | AGA and Watermark (manufacturer-stated) |
| Sizes | 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2" |
Key specifications
| Dixon part number | Size | Working pressure |
|---|---|---|
| SS2P-MF-08MM | 1/4" (8 mm) | 1000 PSI CWP |
| SS2P-MF-10MM | 3/8" (10 mm) | 1000 PSI CWP |
| SS2P-MF-15MM | 1/2" (15 mm) | 1000 PSI CWP |
| SS2P-MF-20MM | 3/4" (20 mm) | 1000 PSI CWP |
| SS2P-MF-25MM | 1" (25 mm) | 1000 PSI CWP |
| SS2P-MF-32MM | 1-1/4" (32 mm) | 1000 PSI CWP |
| SS2P-MF-40MM | 1-1/2" (40 mm) | 1000 PSI CWP |
| SS2P-MF-50MM | 2" (50 mm) | 1000 PSI CWP |
Dixon's catalogue prints the metric size of the 1/4 in and 1/2 in valves as 6 mm and 12 mm. The store size follows the part number (8 mm and 15 mm); the inch size is the same in both.
Selecting the right option
Match the end threads to your pipework first: both ends of this valve are BSP. If your lines are NPT, Dixon lists a separate two-piece NPT valve in its range. For hot or aggressive service, confirm the media and operating temperature with Dixon before ordering, because the catalogue gives the pressure rating but no temperature range for this valve.
Related products
Related Dixon valves: Dixon 316 Stainless Steel Two Piece Ball Valve BSP Female x Female, Dixon Deadman Stainless Steel Spring Return Handle Ball Valve Female BSP x Female BSP and Dixon 316 Stainless Steel Ball Valve 3-Way L Port Female Thread BSP.
