Dixon SAS22015 1/2" (15 mm) Deadman Ball Valve 316 SS BSP F x F

This Dixon deadman ball valve has a spring-return handle, so it closes by itself unless the operator holds it open. It is the three-piece version, with a 316 stainless steel body, a PTFE seat, CF8M (316 stainless steel) trim and female BSP ends. Dixon lists it in 5 sizes, from 1/2" to 2" (manufacturer-stated).

Dixon rates the range at 1000 PSI (69 bar) and positions it as a fail-safe closed valve for petrochemical and other media where spillage could cause damage or injury if an operator opened the valve by mistake (manufacturer-stated). A two-piece version and a 2000 PSI NPT option are listed by Dixon on request.

Where this product is used

• Fail-safe closed isolation on petrochemical and other media where an accidental spill could cause damage or injury (manufacturer-stated).
• Sample, drain and transfer points where the valve should only stay open while someone holds the handle.

Features

• Deadman, spring-return handle: the valve returns to closed when released (manufacturer-stated)
• Three-piece design; a two-piece version is also listed by Dixon (manufacturer-stated)
• Body: 316 stainless steel; seat: PTFE; trim: CF8M (316 stainless steel) (manufacturer-stated)
• End connection: female BSP (manufacturer-stated)
• Working pressure: 1000 PSI (69 bar) (manufacturer-stated)

Common specifications

Key specifications

Dixon's catalogue prints the metric size of the 1/2 in valve as 12 mm. The store size follows the part number (SAS22015 is listed as 15 mm); the inch size is the same in both.

Selecting the right option

A deadman valve only stays open while the handle is held, so it suits attended draw-off points and not lines that must run unattended. Both ends are female BSP, so each side needs a male BSP thread. For a different pattern, ask us about the two-piece deadman valve (SS2PSR series) and the 2000 PSI NPT option that Dixon lists on request.
