Dixon Anfo Loader Spare Part Sub Assembly Cross BSP Stainless Steel
Out of stock
This Dixon cross is a four-way 316 stainless steel pipe fitting with 1/2" BSP threads. It is reference 5 in the manifold assembly for the remote control version of its Minsup® ANFO loader. The 1/2" cross is the only stainless steel size in that table; the larger crosses are galvanised malleable iron.
Where this product is used
- Branching a stainless steel BSP line four ways in a manifold, as in the Minsup® remote control manifold assembly
- Replacing a cross in an ANFO loader manifold, using the numbered spare parts list
Features
- 316 stainless steel cross, 1/2" BSP
- Reference 5 in the remote control manifold assembly parts list
- Section rating: 300 PSI working pressure, Class 150 lb design
- Thread standard: ISO 7-1 pipe threads
Key specifications
| Specification | Detail |
|---|---|
| Brand | Dixon |
| Description | Cross, 1/2" BSP, 316 stainless steel |
| Thread size | 1/2" BSP |
| Material | 316 stainless steel (CF8M body) |
| Working pressure | 300 PSI (stainless steel BSP fittings range) |
| Thread standard | ISO 7-1 pipe threads |
| Used in | Minsup® manifold assembly, remote control version (reference 5) |
Choosing the right option
There is one stainless steel cross size in Dixon's range, 1/2" BSP, so the choice is about thread type: check that the other fittings in your manifold are BSP and not NPT. The galvanised malleable iron cross (FMG-CRO-15) is a different material with its own ratings.
Related Dixon ANFO loader parts: Dixon Anfo Loader Spare Part Sub Assembly Reducing Bush 1/2" x 1/4" BSP, Dixon Anfo Loader 1/2" BSP Replacement Air Regulator 0-1000 kPa and Dixon Anfo Loader 1/4" BSP Replacement Pressure Gauge 0 - 1000 PSI.
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Dixon Anfo Loader Spare Part Sub Assembly Cross BSP Stainless Steel
SKU: A0157442 | Model: SS16CR015
Dixon SS16CR015: 1/2" BSP cross.
