Dixon 40MP-U100RJT 1" Black Buna-N RJT Gasket Red Dot
Available
This Dixon Buna-N (NBR) gasket is the O-ring seal for BSM (RJT) hygienic unions. It is black with a red dot marking and is listed in 6 sizes, 1 in, 1-1/2 in, 2 in, 2-1/2 in, 3 in, 4 in (manufacturer-stated).
Dixon lists it in its BSM (RJT) O-rings group, which Dixon associates with RJT (BSM) AS1528.2 - 2001 screwed couplings (manufacturer-stated). The catalogue gives the inside diameter and width of each O-ring, shown in the table below. Dixon notes that FKM is also available for this range.
Where this product is used
- Replacement O-ring seal for BSM (RJT) hygienic unions in the matching size (manufacturer-stated).
- Union joints between RJT liners and males where a Buna-N seal suits the product and cleaning chemicals.
Features
- Material: Buna-N (nitrile, NBR) (manufacturer-stated)
- Used with BSM (RJT) screwed couplings to AS1528.2 - 2001 (manufacturer-stated)
- Inside diameter and width listed for every size (manufacturer-stated)
- Part number series: 40MP-U...RJT (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Material | Buna-N (nitrile, NBR) |
| Used with | BSM (RJT) hygienic unions (RJT (BSM) AS1528.2 - 2001, manufacturer-stated) |
| Marking | Black, red dot |
| Sizes | 1", 1-1/2", 2", 2-1/2", 3", 4" |
Key specifications
| Dixon part number | Size | Inside dia. (mm) | Width (mm) |
|---|---|---|---|
| 40MP-U100RJT | 1" | 26.92 | 6.35 |
| 40MP-U150RJT | 1-1/2" | 39.62 | 6.35 |
| 40MP-U200RJT | 2" | 52.32 | 6.35 |
| 40MP-U250RJT | 2-1/2" | 65.08 | 6.35 |
| 40MP-U300RJT | 3" | 77.72 | 6.35 |
| 40MP-U400RJT | 4" | 103.12 | 6.35 |
Inside diameters and widths are from the standard BSM (RJT) O-rings table in Dixon's hygienic fittings catalogue.
Selecting the right option
Match the O-ring to the union size, and check that your union is a BSM (RJT) type with the standard liner and male: Dixon's CIP flat-face unions and its NZ RJT unions use different O-rings and gaskets (manufacturer-stated). Choose Buna-N only if it suits your product and cleaning chemicals. Dixon also lists FKM RJT O-rings (the 40MP-SFY...RJT series); ask us if you need them. Dixon's compound guide rates Buna as satisfactory (A) for vegetable oils, mineral oil and kerosene, and as unsatisfactory (D) for acetone and ozone (manufacturer-stated). Those ratings assume static conditions at ambient temperature, and Dixon describes the guide as general only, with suitability for a specific application resting with the end user (manufacturer-stated).
