Dixon PVC drum pump hose for fuel and oil, 25mm
Out of stock
This Dixon PVC hose is made for dispensing fuel and oil from overhead tanks and drums. It has a black PVC tube, a smooth black PVC cover and polyester yarn reinforcement, it is UV stabilised and abrasion resistant, and it is extruded. It comes in the 25mm and 32mm sizes.
The H110 range is rated at 150 PSI (10 bar) working pressure and 600 PSI (40 bar) burst, for temperatures from -5 to 60°C.
Where this product is used
- Dispensing fuel and oil from overhead tanks and drums
- Fuel and oil transfer lines from drums and tanks, within the pressure and temperature range
Features
- Tube: PVC, black, cover: PVC, smooth, black, polyester yarn reinforcement
- Working pressure 150 PSI (10 bar), burst 600 PSI (40 bar)
- Temperature range -5 to 60°C
- UV stabilised and abrasion resistant
Key specifications
| Specification | Detail |
|---|---|
| Brand | Dixon |
| Tube | PVC, black |
| Cover | PVC, smooth, black |
| Reinforcement | Polyester yarn |
| Working pressure | 150 PSI (10 bar) |
| Burst pressure | 600 PSI (40 bar) |
| Temperature | -5 to 60°C |
| Sizes | 25mm, 32mm |
Choosing the right option
Pick the size from the pump or tank outlet and use hose tails or fittings made for fuel and oil service. Keep the hose within the -5 to 60°C range and out of heat sources.
Related Dixon hose: Dixon Rubber Petrol & Oil Delivery Hose, Dixon Rubber Petrol & Oil Suction & Delivery Hose and Dixon PVC Medium Heavy Duty Petrol & Oil Suction Hose.
| Option | Part number | SKU |
|---|---|---|
| 25 | H1102520 | A0070387C20 |
| 32 | H1103220 | A0070388C20 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Dixon PVC Drum Pump Hose: 25
SKU: A0070387C20 | Model: H1102520
Dixon H1102520: 25mm PVC drum pump hose, 150 PSI (10 bar). Hose ID: 25.4mm, Hose OD: 34mm, Bend radius: 155mm.
