Dixon Petrol and oil discharge hose, 20 / 10 m

This Dixon rubber hose is made for transferring petroleum and oil products with a maximum of 50% aromatic content, and it suits tank trucks and general industrial use, including some reeling applications. It has a black NBR tube, a black SBR/EPDM blend cover, high tensile synthetic textile cord reinforcement and an anti-static copper wire, and it is mandrel built. All sizes are rated at 150 PSI (10 bar) working pressure and 450 PSI (30 bar) burst, for temperatures from -35 to 80°C.

It comes in 20, 32, 38 and 51mm hose as 10 m cut lengths and in 20 m and 60 m coils.

Where this product is used

• Transferring petroleum and oil products with a maximum of 50% aromatic content
• Tank truck and general industrial discharge lines
• Some reeling applications

Features

• Tube: NBR, black, cover: SBR/EPDM blend, black, textile cord reinforcement
• Anti-static copper wire, mandrel built
• Working pressure 150 PSI (10 bar), burst 450 PSI (30 bar)
• Temperature range -35 to 80°C
• For petroleum and oil products up to 50% aromatic content

Key specifications

Choosing the right option

Use this hose on the discharge side of the pump. Check the fuel or oil against the 50% aromatic limit and use fittings and clamps made for fuel hose. The anti-static copper wire needs to be bonded through the fittings to earth the hose.

The 10 m and 60 m lengths are option names.

Related Dixon hose: Dixon Rubber Petrol & Oil Suction & Delivery Hose, Dixon PVC Medium Heavy Duty Petrol & Oil Suction Hose and Dixon Rubber Fuel Hose.
