Macnaught Bottom Adaptor Set - NPT Spare Part TG022S
Available
The Macnaught TG022S is the NPT thread bottom adapter for the Macnaught R500 air-operated oil pump.
BSP and NPT are two pipe thread standards. Threads on its pumps are NPT in the USA and Canada and BSP elsewhere, unless specified otherwise. The R500 is a 5:1 ratio pump. It has a 1/4" air inlet (female), a 3/4" pump outlet (female) and a 2" bung adaptor (male).
Where this product is used
- Replacing the bottom adapter on a Macnaught R500 pump
- Pump rebuilds where the R500 service kits do not cover the adapter
Features
- Bottom adapter (NPT thread version) for the Macnaught R500 pump
- R500: A 1/4" air inlet (female), a 3/4" pump outlet (female) and a 2" bung adaptor (male)
- Disconnect the air supply and bleed the oil line by squeezing the gun trigger before any maintenance
- Do not exceed 1035 kPa air inlet pressure. Run at about 690 kPa
Key specifications
| Specification | Detail |
|---|---|
| Brand | Macnaught |
| Part number | TG022S |
| Part type | Bottom adapter (NPT) |
| Fits | Macnaught R500 air-operated oil pump |
| Pump ratio | 5:1 |
| Thread standard | NPT |
Supplied with
- Bottom adapter only
- Service kits are separate
