Maxigear Thread Plug Gauge Metric Set

The Maxigear Thread Plug Gauge Metric Set - Pack of 7 is part of the Maxigear range — precision engineering tools and machining accessories designed for toolmakers, machinists, and precision engineers across Australian industry. Maxigear products are selected by engineering workshops, tool rooms, CNC shops, trade schools, and industrial maintenance teams for reliable performance in demanding machining and measurement applications.

Where this product is used

Maxigear thread plug gauges provide a reliable go/no-go check of tapped hole thread form, ensuring machined components meet assembly and tolerance requirements before leaving the workshop.

• Verifying tapped hole thread form and pitch to tolerance before assembly
• Go/no-go inspection of threaded holes in machined components for quality assurance
• Production and toolroom inspection of metric threads to ensure correct fit before assembly

Key specifications

Selecting the right option

Select the thread plug gauge in the metric pitch and diameter that matches the tapped hole specification on your drawing. The seven-piece metric set provides coverage of common M3–M12 pitches for toolroom inspection programs. For production use, select individual go/no-go gauges in the specific thread size being checked.
