Bremick WRMSGSM08 M8 x 14.8mm x 2mm Metric Spring Washer, Hot Dip Galvanised
The price shown is for the box.
Available
A spring washer is a split ring fitted under a nut or bolt head. There are 6 Bremick metric spring washer items (metric thread, spring steel, hot dip galvanised finish): M8 to M24.
Size is the nominal thread size the washer is made for. The outside diameter and thickness are the figures listed with each size; the product data does not give the hole (inside) diameter.
The product data does not state a standard for these spring washers, so none is published.
The pack or box quantity for each item is shown in the table. It changes with the size.
Where this product is used
- Under nuts and bolt heads where some resistance to loosening from vibration is wanted
- Motor mounts, covers and guards that see machine vibration
- Bolted joints in light fabrication, fitted with a flat washer where the surface needs protecting
- Outdoor and long-term exposure, including structural steelwork, roofing and fencing
- Choosing between the 6 items here: they cover diameters from M8 to M24.
Choosing the finish
Hot dip galvanised parts are the usual pick for work that stays outside for years, such as structural steelwork, roofing and fencing, because the zinc coating is thick.
They are generally suitable for treated pine in many hazard classes, so check the timber supplier's fastener requirement. Within about 1 km of the sea, or in splash zones, 316 stainless is generally the better choice.
Matching the bolt
The spring washer helps to resist loosening, though not completely. Match the size to the bolt, and add a flat washer under it on soft or painted surfaces.
Features
- 6 items: M8 to M24
- Metric thread, spring washer
- Spring steel, hot dip galvanised finish
- Pack quantity shown for each item
- Hot dip galvanised finish, for outdoor and weather-exposed work
- Material: spring steel
Common specifications
| Specification | Detail |
|---|---|
| Sizes | M8 to M24 |
| Washer type | Spring washer |
| Material | Spring steel |
| Finish | Hot dip galvanised |
Key specifications
| Model | Size | Outside diameter | Thickness | Supplied as |
|---|---|---|---|---|
| WRMSGSM08 | M8 | 14.8mm | 2mm | Box of 200 |
| WRMSGSM10 | M10 | 18.1mm | 2.2mm | Box of 200 |
| WRMSGSM12 | M12 | 21.1mm | 2.5mm | Box of 200 |
| WRMSGSM16 | M16 | 27.4mm | 3.5mm | Box of 200 |
| WRMSGSM20 | M20 | 33.6mm | 4mm | Box of 100 |
| WRMSGSM24 | M24 | 40mm | - | Pack of 300 |
Selecting the right option
Choose the size by the bolt or screw diameter the washer goes on, then check the outside diameter and thickness against your joint. The outside diameter and thickness are shown for each size in the table. For a flat washer to spread the load, see the related flat round washers.
Related products
Related washers: Bremick Metric Spring Washer, Spring Steel, Zinc, M6 to M24, Bremick Metric Flat Round Washer, Mild Steel, Hot Dip Galvanised, M6 to M64 and Bremick Metric Flat Round Washer, Mild Steel, Plain, M6 to M56.
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bremick Metric Spring Washer, Spring Steel, Hot Dip Galvanised, M8 to M24: M8 x 14.8 mm x 2 mm
SKU: A0086709 | Model: WRMSGSM08
Bremick WRMSGSM08: M8 spring washer, 14.8mm OD x 2mm thick, spring steel, hot dip galvanised. Box of 200.
