Stahlwille 49X XZN Screwdriver Socket M6, 3/8" Drive

Stahlwille 49X M6 is an XZN screwdriver socket for 3/8" drive: an M6 XZN tip, 52mm long, 47 g, for tri-square socket head screws (XZN). It has a 3/8" internal square drive at the other end, so it turns on a 3/8" drive ratchet, handle or extension. The socket is Chrome Alloy Steel, chrome plated, and is made to DIN 2324.

A bit socket in a ratchet gives a faster and more compact drive than a screwdriver handle. The M number is the XZN size, so match it to the recess in the screw head. The other sizes are separate products. These sockets are for hand use, so keep to hand-driven work.

Where this product is used

• M6 XZN tri-square socket head screws
• XZN screws where a 3/8" drive ratchet gives better access than a screwdriver
• Replacing a worn or missing XZN screwdriver socket from a 3/8" drive set

Features

• M6 XZN tip
• 52mm long
• 3/8" internal square drive
• For tri-square socket head screws (XZN)
• Chrome Alloy Steel, chrome plated
• Made to DIN 2324
• For hand use

Key specifications

Choosing the right option

Pick the size by the XZN recess in the screw head. The other sizes are the 49X XZN screwdriver socket M5, 3/8" drive, 49X XZN screwdriver socket M8, 3/8" drive and 49X XZN screwdriver socket M10, 3/8" drive. Turn it with a 422 3/8" drive reversible ratchet or 435 3/8" drive reversible ratchet; the 427 3/8" drive extension bars add reach and the 428 3/8" drive universal joint lets you work at an angle. For hexagon and Torx tips on the same drive see the 49 INHEX sockets, 3/8" drive and the 49TX Torx screwdriver sockets, 3/8" drive.
