Description

Trax 5/16" Heavy Duty Air Hydraulic Riveter ARX-380

Traction Power (kgf / lbf)
1,723 / 3,800 at (85psi)
Stroke Length (mm)
22.5
Net Weight (kg)
1.88
Working Air Pressure (psi)
85 - 95
Nosepiece
3/16" (4.8mm)1/4" (6.4mm)7/32" (5.6mm)5/16" (7.8mm)
Width x Height (mm)
305 x 310
Air Consumption (cfm)
0 - 4
Vacuum
YES
Capacity
3/16" (4.8mm)1/4" (6.4mm)7/32" (5.6mm)5/16" (7.8mm) In all material

Specifications

Specification:

Applications

Features & Benefits

Features:

Largest power 3,800lb-f
Long Stroke 22.5mm
Set 3/16" and 5/16" to structure around Monobolt rivets, T-type rivets and standard rivets in all materials
Low recoil of shock-less ca reduce parts consume and minimise fatigue

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Trax ARX-380 5/16" Heavy Duty Air Hydraulic Riveter

Name: Trax ARX-380 5/16" Heavy Duty Air Hydraulic Riveter
Brand: Trax
SKU: A0141515
Price: 1186.50 AUD
Availability: InStock

SKU: A0141515

Type: Air Hydraulic Riveter

$1,186.50

Tax included. Shipping calculated at checkout.

Wide Range
Reliable Services
Proven Trust

Available

The Trax ARX-380 5/16" Heavy Duty Air Hydraulic Riveter by Trax is a Air Hydraulic Riveter for all materials. It provides 3,800lb-f traction power at 85psi and is for Pneumatic Tools in industrial workshop riveting operations.
