Wiha phillips DuraBit PH1 and PH2, PH1
Available
Wiha series 7041DR DuraBit Phillips bits with a torsion zone for the 1/4" hex drive (style E 6.3), in PH1 (23388) and PH2 (23390), both 50mm long.
The tip has a hard-metal coating: a non-corroding nickel coating with wolfram carbide particles.
Where this product is used
- Demanding industrial applications and delicate surfaces
Features
- Hard-metal coating: non-corroding nickel coating with wolfram carbide particles
- Patented torsion zone to prevent the bit breaking prematurely under stress
- Chrome-vanadium steel, through hardened
- Drive to DIN 3126, ISO 1173, style E 6.3 (1/4" hex)
Key specifications
| Specification | Detail |
|---|---|
| Brand | Wiha |
| Series | 7041DR |
| Phillips sizes | PH1 and PH2 |
| Overall length | 50mm |
| Drive | 1/4" hex, DIN 3126, ISO 1173, style E 6.3 |
| Coating | Hard-metal: nickel with wolfram carbide particles |
| Torsion zone | Patented |
| Material | Chrome-vanadium steel, through hardened |
| Phillips size | PH1, PH2 |
Choosing the right option
Choose PH1 or PH2 to match the screw head; both are 50mm long. For uncoated Phillips power bits in more lengths see the Phillips Power Insert Bit 1/4" Hex, and for torsion bits without the coating see the Wiha Phillips Power Insert Bit 1/4" Hex - 7041ZOT Series.
See also: Phillips Power Insert Bit 1/4" Hex, Wiha Phillips Power Insert Bit 1/4" Hex - 7041ZOT Series, Wiha PH2 x 25mm Phillips Insert Bit 1/4" Hex With Torsion Zone.
| Option | Part number | SKU |
|---|---|---|
| PH1 | 23388(7041DR) | A0144524 |
| PH2 | 23390(7041DR) | A0144525 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Wiha Phillips Power Insert Bit Dura Tip: PH1
SKU: A0144524 | Model: 23388(7041DR)
Wiha 23388(7041DR): PH1 Phillips DuraBit, 50mm long, 1/4" hex drive (style E 6.3), hard-metal coated tip, torsion zone.
