2 in (50 mm) Cast Steel Check Valve, ANSI 300 | VSC30050

This AAP cast steel flanged check valve has a WCB (ASTM A216) body and bonnet, a 410 (2Cr13) disc, a Stellite seat and ANSI Class 300 flanges. It is supplied in 4 sizes from 2 in (50 mm) to 8 in (200 mm).

A check valve lets fluid flow one way and closes against reverse flow, which protects pumps and equipment upstream. AAP does not say whether this valve is a swing or a lift pattern, so confirm the type and the mounting positions it suits with AIMS before you order if orientation matters.

AAP gives a maximum working temperature of 440 degrees C and a cold working pressure of 5,100 kPa (51 bar), with design to ANSI B16.34 and flange dimensions to ANSI B16.5 (all manufacturer-stated). AAP does not list applications for this valve. The pressure figure is the cold working pressure, so the allowable pressure falls as the temperature rises. Ask AIMS for the pressure and temperature rating if the valve will run hot.

Where this product is used

• Preventing reverse flow on hot and high pressure flanged lines
• Process and utility pipework in steel flanged systems
• Pump discharge lines in steel pipework
• Plant isolation of reverse flow where a cast steel valve is specified

Features

• 4 sizes from 2 in (50 mm) to 8 in (200 mm)
• WCB (ASTM A216) body and bonnet
• 410 (2Cr13) disc with a hard-faced Stellite seat, graphite gasket
• ANSI Class 300 flanges to ANSI B16.5 (manufacturer-stated)
• Cold working pressure 5,100 kPa (51 bar), maximum 440 degrees C (manufacturer-stated)
• Design to ANSI B16.34 (manufacturer-stated)

Materials

Key specifications

Options and part numbers

L is the length of the valve and H is its height, as shown on the AAP drawing.

Selecting the right option

Choose the size to match your ANSI Class 300 flanges, and check the hole count and hole diameter against your mating flange. Confirm the pressure and temperature rating for your duty with AIMS, and allow room for the valve to open.

Related products

See also AAP Cast Steel Flanged Check Valve, ANSI 150, AAP Forged Steel Piston Check Valve, Class 800, NPT, AAP Forged Steel Piston Check Valve, Class 800, Socketweld and AAP Cast Steel Flanged Globe Valve ANSI 300.
