Dixon DDT1 Diameter Tape

This is a Dixon diameter tape, part number DDT1. A diameter tape is looped once around a pipe or hose and read against its marked scale, which gives the outside diameter without a calliper.

The Dixon documents we hold do not list DDT1, so the scale, tape length and case are not stated on this page. Check them with us before you order if you need a particular scale.

Where this product is used

• Measuring the outside diameter of hose or pipe from its circumference.
• Checking hose ends before choosing a clamp or ferrule that is selected by outside diameter.

Features

• Diameter tape, Dixon part number DDT1
• Measures outside diameter by wrapping the tape around the part

Key specifications

Selecting the right option

A diameter tape reads the outside diameter of what it is wrapped around, so measure at the point you need and pull the tape snug without stretching it. If you work on roll grooved pipe, Dixon lists the DDTM diameter tape, which carries roll grooved dimensions (linked below).
