Dixon HA0226 2" External Crimp Female Stem Holedall BSM (RJT)

This Dixon Holedall stem is a female BSM (RJT) external crimp stem in 316 stainless steel, made for inch-bore hose. Dixon lists it in six sizes from 1" (HA0224) to 4" (HA0294). The coupling follows the RJT (BSM) standard AS 1528.2 - 2001 for screwed couplings (manufacturer-stated).

The stem is crimped onto the hose with a Holedall external crimp ferrule. The matching male stems are HA0219 to HA0223 and HA0293. Dixon states that its stems are made to suit inch-bore hose and not metric hose, so measure the hose inside diameter before you order (manufacturer-stated).

Where this product is used

• Hygienic hose assemblies that need a female RJT (BSM) end.
• Connecting a hose to a male RJT (BSM) fitting or to a male stem from the same range.

Features

• 316 stainless steel external crimp stem (manufacturer-stated)
• Female BSM (RJT) end, listed to AS 1528.2 - 2001 for screwed couplings (manufacturer-stated)
• Made to suit inch-bore hose, not metric hose (manufacturer-stated)
• Six sizes from 1" to 4" (manufacturer-stated)

Common specifications

Key specifications

Millimetre sizes are the figures in Dixon's hygienic catalogue.

Selecting the right option

Choose the stem by the inside diameter of the hose, in inches, then choose a ferrule to suit the hose outside diameter. Dixon lists the matching 304 stainless steel Holedall external crimp ferrules as HA0249 (1"), HA0250 (1-1/2"), HA0251 (2"), HA0252 (2-1/2"), HA0253 (3") and HA0301 (4"), each with a dash number that is chosen by the hose outside diameter (manufacturer-stated). Use the female stem when you are connecting to a male RJT (BSM) fitting, and the male stem (HA0219 to HA0223 and HA0293) when you are connecting to a female one.

Related products

Related Dixon products: Dixon Clamp Type / Tri-Clover External Crimp Stem and Dixon Tube Crimp Stem Buttweld.
