Hobson WRMSGSQ100018 1" Imperial Spring Washer, Square Section
Available
This page lists 7 items of the Hobson imperial spring washer, square section (mild steel, hot dip galvanised): 1/4" to 1".
A spring washer is a split ring fitted under a nut or bolt head. In a square section spring washer the ring has a square cross-section.
The supplier item description lists each size as two figures without labels. They are shown as listed, and labelled only where the store option states them.
Pack quantity varies by size and is shown for each item in the table.
Where this product is used
- Fitted under a nut or bolt head as a spring washer
- Where an assembly calls for a spring washer under the nut
Features
- 7 items: 1/4" to 1"
- Mild steel, hot dip galvanised
- Dimensions shown as listed by the supplier
- Pack quantity shown for each item
Common specifications
| Specification | Detail |
|---|---|
| Sizes | 1/4" to 1" |
| Material | Mild steel |
| Finish | Hot dip galvanised |
Key specifications
| Model | Size | Listed dimensions | Supplied as |
|---|---|---|---|
| WRMSGSQ025006 | 1/4" | 1/4" x 1/16" | Box of 200 |
| WRMSGSQ031007 | 5/16" | 5/16" x 5/64" | Box of 200 |
| WRMSGSQ037009 | 3/8" | 3/8" x 3/32" | Box of 200 |
| WRMSGSQ050011 | 1/2" | 1/2" x 7/64" | Box of 200 |
| WRMSGSQ062012 | 5/8" | 5/8" x 1/8" | Box of 200 |
| WRMSGSQ087018 | 7/8" | 7/8" x 3/16" | Box of 100 |
| WRMSGSQ100018 | 1" | 1" x 3/16" | Box of 50 |
Selecting the right option
Choose the washer by the bolt size it is made for, then check the dimensions in the table: more than one thickness is listed for some sizes. Hot dip galvanising is a zinc coating that is thicker than zinc plating. For a similar washer in another material, finish or size range see Hobson Imperial Spring Washer, Square Section, Zinc Plated, 1/8" to 1".
Related products
Related washers: Hobson Imperial Spring Washer, Square Section, Zinc Plated, 1/8" to 1", Hobson Metric Spring Washer, Flat Section, Hot Dip Galvanised, M6, M30 and M36 and Hobson Metric Spring Washer, Flat Section, Zinc Plated, M3 to M5.
