M5 (3.2mm wire) Lag/swage Rigging Screw, 316 Stainless Steel - 0493B
Available
This 316 stainless steel lag/swage rigging screw is a rigging screw that tensions wire rope. It has a lag-style threaded end and a swage end for wire rope, and turning the body tightens or loosens the line.
This listing is a single size: M5 (3.2mm wire). Each variant is supplied in packs of 10.
The A4 (316) grade is stainless steel with added molybdenum, which helps it hold up where salt, pool chemicals or washdown chemicals are present. It is the more corrosion-resistant of the two common stainless grades, at a higher cost than 304. Metric sizes are written M followed by the nominal thread diameter in millimetres, so M10 is a 10 mm thread.
In wet conditions, keep stainless steel apart from aluminium and galvanised steel with a washer or sleeve, to reduce the risk of galvanic corrosion.
Where this product is used
- Outdoor fittings exposed to salt air
- Shade sails, awnings and tensioned structures
- Boat, jetty and waterfront structures
- Wire runs that finish in a lag-style threaded end
- Balustrade and wire fencing
Features
- Metric thread sizes match the nuts, bolts and tapped holes in most Australian-supplied equipment
- Swage end is pressed onto the wire rope
- Adjusts the tension of a wire rope run
- A4 (316) stainless steel with molybdenum, for coastal and chloride-exposed settings
- Pack quantities to suit trade and bulk buying: packs of 10
Key specifications
| Specification | Detail |
|---|---|
| Product | M5 (3.2mm wire) Lag/Swage Rigging Screw |
| Type | Rigging screw that tensions wire rope |
| Material | A4 (316) stainless steel |
| Magnetic response | Generally non-magnetic (austenitic); cold-worked parts can show weak magnetism |
| Key features | Adjusts the tension of a wire rope run; Swage end is pressed onto the wire rope |
| Pack quantity | 10 |
| Variants | 1 |
| Fitting tip | Use anti-seize on the thread to reduce galling |
| Environment | Coastal, marine, pool and food-processing use |
| Thread system | Metric |
Selecting the right option
Choose the rigging screw by the thread size and the wire rope diameter listed on the variant. A swaging tool is needed for the swage end, and the thread should be lubricated with anti-seize.
Important
This product is not stated as lifting rated in the supplier data. Do not use it to lift or suspend people or loads unless it is marked with a working load limit (WLL). Rigging and lifting hardware should be selected, inspected and used in line with your site procedures and the relevant Australian Standards, and a qualified rigger should be consulted for any lift.
