Descriptions

• Grade T(80) Zinc Plated, calibrated European load chain for increased resistance against corrosion and wear.
• Custom lifts are available on request.
• Chain inspection gauge supplied with every hoist in order to self evaluate wear and tear on load chain.
• 5 pocket precision-machined load sprocket for smooth action.
• Reduction gearbox is totally sealed, grease-filled design ensuring that all components remain lubricated.
• Zinc Plated travel limiting springs.
• Overload clutch to prevent damage from overloading.
• European electric controls (contactors and switchgear).
• IP54 Protection on electric hoist for dust and waterproof protection.
• Thermal protection on hoist motor.
• Heavy-duty asbestos-free DC brake (for fast actuation).
• Upper and lower limit switches fitted as standard to prevent over travel.
• Contactor isolation emergency stop.
• 24 Volt control via IP65 European pendant for increased safety.
• Pendant control suspended by external wire rope (Strained Wire).
• Sealed swivel bearing in bottom hook for 360° operation.
• Heavy-duty cast safety latches fitted to Top and bottom hook on all models.
• High duty cycle (up to 40% ED on 3 phase models).
• Chain containers on all hoists.
• Comprehensive instruction manual, including wiring diagrams and parts breakdown, supplied with every hoist.
• Powder-coated finish.
• Test Certificate supplied with every hoist confirming that it is tested to AS 1418.2
• Electric trolley model type: available to suit a wide range of beam widths.

Material: Stainless steel

Applications: For lifting purposes

Other Features

• Available in standard lifts of 3 and 6 metres
• Models available in single phase 240 volts X 50Hz and 3 phase 415 volts X 50Hz.
• Capacities from 500 kg to 3000 kg in both single and 3 phase.
