Dixon A104012 12.5 mm x 60 m Red Rubber Non-Conductive Hose

This listing is the red 12.5 mm ID Dixon A104 multi-purpose non-conductive hose, part number A104012, listed in the store as a 60 m length. Dixon lists the A104 range for conveying air, oil, water, kerosene, some chemicals and other media where oil resistance matters, and describes the hose as non-conductive and UV stabilised (manufacturer-stated). It has a black NBR blend tube, a red NBR blend cover and polyester yarn reinforcement.

Dixon rates the 12.7 mm size at 300 PSI (20 bar) working pressure and 1200 PSI (80 bar) burst, for temperatures from -20 to 100 degrees C (manufacturer-stated). Its catalogue figures are an OD of 22 mm, a bend radius of 100 mm and 0.40 kg/m.

Where this product is used

• Conveying air, oil, water, kerosene and some chemicals where oil resistance is needed (manufacturer-stated).
• Colour-coded lines where red hose marks one medium (manufacturer-stated).

Features

• Black NBR blend tube with red NBR blend cover; polyester yarn reinforcement (manufacturer-stated)
• Working pressure 300 PSI (20 bar), burst 1200 PSI (80 bar) (manufacturer-stated)
• Temperature range -20 to 100 degrees C (manufacturer-stated)
• Non-conductive and UV stabilised (manufacturer-stated)
• Listed in the store as 12.5 mm ID x 60 m (manufacturer-stated)

Key specifications

Selecting the right option

Confirm the length before you order: the store title says 60 m, while Dixon's catalogue lists A104012 as the cut-length number for this hose and A104012020 and A104012100 as the 20 m and 100 m coils. Pick the size from your fitting bore. For other colours and sizes, see the A104 range in Related products.
