Dixon Brass Y line strainer, 1/2"

This Dixon Y line strainer has a cast brass body, a 316 stainless steel mesh and female BSP connections at both ends. It comes in 8 sizes, from 8mm to 2", and every size has a 500 micron degree of filtration. The range is rated at a maximum of 290 PSI (20 bar), with -15 to 110°C for air and 0 to 90°C for water.

It suits domestic water services, heating and air-conditioning plants and compressed air systems.

Where this product is used

• Domestic water services, heating and air-conditioning plants and compressed air systems
• A strainer ahead of a valve, meter or pump, to catch particles before they reach it

Features

• Cast brass body with a 316 stainless steel mesh
• Female x female BSP connections, equivalent to DIN259 and BS2779
• Degree of filtration: 500 micron
• Maximum working pressure 290 PSI (20 bar)
• Air -15 to 110°C, water 0 to 90°C

Key specifications

Choosing the right option

Match the strainer to the line size and check that the BSP thread on your fittings suits a female BSP connection. Look at the mesh from time to time, because a blocked mesh restricts flow.

The smallest strainer is 8mm and prints its inch size as 5/16".
