Dixon Composite chemical hose, 38mm x 5 m

This Dixon hose is a lightweight composite chemical hose with a white composite tube, a grey composite cover, polypropylene film and fabric reinforcement, a galvanised steel outer wire and a poly-coated inner wire. The range is anti-static and mandrel built, it is constructed in accordance with EN 13765 hose and assembly standards, Type 2. The hose is rated at 150 PSI (10 bar) working pressure, 750 PSI (50 bar) burst and 0.9 bar vacuum, for -30°C to 80°C.

It comes in 38, 50, 63 and 76mm ID, each as a 5 m cut length and a 40 m length.

Where this product is used

• Suction and discharge of a wide range of chemicals, the hose is used with pumps, process equipment, road tankers and rail tankers
• Chemical transfer on plant, rail and road tankers, mine sites and chemical manufacturing plants

Features

• Composite construction: white tube, grey cover, polypropylene film and fabric reinforcement
• Galvanised steel outer wire and poly-coated inner wire
• Anti-static, ozone, weather, abrasion, chemical and oil resistant
• Working pressure 150 PSI (10 bar), burst pressure 750 PSI (50 bar), vacuum 0.9 bar
• Temperature range -30°C to 80°C
• Constructed in accordance with EN 13765:2018 Type 2

Key specifications

Choosing the right option

Check your chemical against the hose materials, because the same working pressure applies across the range but chemical resistance depends on the product and temperature. For assemblies, gather all S.T.A.M.P.E.D. information and proof testing and tagging each assembly.
