Dixon Replacement Anodized Nose Ring With Baylast Gasket Suits 5204 API Valve

This is the replacement anodised nose ring for Dixon 5204 API valves. The kit is the nose ring with its Baylast gasket (nose ring O-ring), nose ring screws and lock washers. The nose ring is anodised hard coat aluminium and can be rotated to give a fresh connection surface, so it is worth checking whether the ring can be turned before it is replaced.

Where this product is used

• Replacing a worn or damaged nose ring on a 5204 series API valve
• Renewing a nose ring that is too worn to be rotated to a fresh position

Features

• Anodised hard coat aluminium nose ring
• Supplied with Baylast nose ring O-ring, screws and lock washers
• Nose ring can be rotated to present a fresh connection surface
• For 5204 series and 5206 series API valves

Key specifications

Choosing the right option

Before replacing the nose ring, check whether it can simply be rotated to a fresh position. The nose ring can be rotated for this reason. If only the screws and washers are needed, Dixon also offers a separate hardware kit (5204K11). Valves with FKM or PTFE seals use different O-rings, so check the seal type fitted to your valve.
