Dixon Concentric reducer, 4 x 2-1/2
Available
This Dixon concentric reducer steps down from a roll grooved pipe end to a female BSP thread on the same centre line. It lets a threaded valve, gauge or branch connect to a grooved line without a separate adaptor. The material is ductile iron (ASTM A536) with a hot dip galvanised finish (AS4680).
It comes in four sizes: 2" x 1", 2-1/2" x 1", 4" x 2-1/2" and 6" x 2-1/2" (50 x 25, 65 x 25, 100 x 65 and 150 x 65 NB). The range is rated at 300 PSI and gives face-to-face lengths of 64, 64, 76 and 102mm. It compares the range with Victaulic No. 52.
Where this product is used
- Connecting a female BSP thread to a roll grooved pipe end in fire protection, water and irrigation pipework where a grooved system is used
- Reducing from a grooved pipe size to a smaller threaded size on one centre line
Features
- Roll grooved large end, female BSP small end, on one centre line
- Ductile iron (ASTM A536), hot dip galvanised finish (AS4680)
- Working pressure: 300 PSI
- The range is UL listed and FM approved
- Comparable to Victaulic No. 52
Key specifications
| Specification | Detail |
|---|---|
| Brand | Dixon |
| Material | Ductile iron (ASTM A536) |
| Finish | Hot dip galvanised (AS4680) |
| Ends | Roll grooved x female BSP |
| Working pressure | 300 PSI |
| Approvals | UL listed and FM approved |
| Comparable to | Victaulic No. 52 |
| Sizes | 50 x 25, 65 x 25, 100 x 65, 150 x 65 NB |
Choosing the right option
Check both ends before ordering: the larger end takes roll grooved pipe, and the smaller end is a female BSP thread, so it needs a male BSP thread. If your pipework is NPT or another thread form, a BSP reducer will not seal correctly. A grooved coupling and gasket are needed at the grooved end.
The pipe OD column shows the grooved end first and the smaller end second; the smaller end is the BSP female thread size.
Related Dixon grooved fittings: Dixon Roll Grooved End Cap - Galvanised, Dixon Roll Grooved Flange Adaptor and Dixon Roll Grooved Mechanical Tee Galvanised.
Couplings: Dixon Roll Grooved Rigid Coupling - Galvanised and Dixon Roll Grooved Coupling Flexible Heavy Duty Galvanised.
| Option | Part number | SKU |
|---|---|---|
| 2 x 1 | FWG-50-60-34-F | A0069908 |
| 2-1/2 x 1 | FWG-50-76-34-F | A0069909 |
| 4 x 2-1/2 | FWG-50-114-76-F | A0069900 |
| 6 x 2-1/2 | FWG-50-165-76-F | A0069904 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Dixon Roll Grooved x Female BSP Concentric Reducer Galvanised: 4 x 2-1/2
SKU: A0069900 | Model: FWG-50-114-76-F
Dixon FWG-50-114-76-F: 4 x 2-1/2" (100 x 65mm) roll grooved x female BSP concentric reducer, 300 PSI. Pipe OD: 114.3 x 76.1mm, Face-to-face: 76mm.
