Dixon A210025020 25 mm x 20 m Rubber Heavy Duty Water Suction & Delivery Hose
Available
This Dixon rubber hose is made for water and light slurry suction and discharge. It has an SBR tube, an SBR/EPDM blend cover and high tensile synthetic textile cords with a steel wire helix, and it is mandrel built (manufacturer-stated). This page covers 8 sizes from 25 to 203 mm, in 20 m and 60 m lengths.
Dixon rates every size in the A210 range at 150 PSI (10 bar) working pressure, 435 PSI (30 bar) burst and 0.9 bar vacuum, for temperatures from -30 to 80 degrees C (manufacturer-stated). The ratings are the same across all sizes; the bend radius and weight change with the bore.
Where this product is used
- Water and light slurry suction and discharge in construction, mining, dewatering, irrigation and municipal work (manufacturer-stated).
- Pump suction lines that need a wire helix to hold the hose open under vacuum (manufacturer-stated).
- Site dewatering runs where the hose is dragged over rough ground, because the cover is abrasion resistant (manufacturer-stated).
Features
- Tube: SBR, black; cover: SBR/EPDM blend, smooth, black (manufacturer-stated)
- Reinforcement: high tensile synthetic textile cords with a steel wire helix (manufacturer-stated)
- Working pressure 150 PSI (10 bar), burst 435 PSI (30 bar), vacuum 0.9 bar (manufacturer-stated)
- Temperature range -30 to 80 degrees C (manufacturer-stated)
- Ozone, weather, oil mist and abrasion resistant; mandrel built (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Tube | SBR, black |
| Cover | SBR/EPDM blend, smooth, black |
| Reinforcement | High tensile synthetic textile cords and steel wire helix |
| Working pressure | 150 PSI (10 bar) |
| Burst pressure | 435 PSI (30 bar) |
| Vacuum | 0.9 bar |
| Temperature | -30 to 80 degrees C |
| Sizes on this page | 25 mm, 32 mm, 38 mm, 51 mm, 76 mm, 102 mm, 127 mm, 203 mm |
| Lengths | 20 m and 60 m (store options) |
Key specifications
| Dixon part number | Size | Length | Catalogue ID (mm) | Catalogue OD (mm) | Bend radius (mm) | Weight (kg/m) |
|---|---|---|---|---|---|---|
| A210025020 | 25 mm | 20 m | 25.4 | 34 | 95 | 0.70 |
| A210025060 | 25 mm | 60 m | 25.4 | 34 | 95 | 0.70 |
| A210032020 | 32 mm | 20 m | 31.8 | 42 | 125 | 1.00 |
| A210032060 | 32 mm | 60 m | 31.8 | 42 | 125 | 1.00 |
| A210038020 | 38 mm | 20 m | 38.1 | 48 | 150 | 1.23 |
| A210038060 | 38 mm | 60 m | 38.1 | 48 | 150 | 1.23 |
| A210050020 | 51 mm | 20 m | 50.8 | 62 | 215 | 1.70 |
| A210080020 | 76 mm | 20 m | 76.2 | 89 | 350 | 3.01 |
| A210100020 | 102 mm | 20 m | 101.6 | 115 | 490 | 4.27 |
| A210125020 | 127 mm | 20 m | 127 | 142 | 650 | 5.87 |
| A210200020 | 203 mm | 20 m | 203.2 | 222 | 1120 | 12.33 |
ID, OD, bend radius and weight are the A210 figures printed in Dixon's Industrial Hose catalogue for each size. Dixon prints its 20 m coil numbers as the cut-length number plus 20 (for example A21002520 for 25 mm); the store part numbers carry an extra zero (A210025020). The 60 m lengths are store options and are not shown in the catalogue table.
Selecting the right option
Choose the hose by internal diameter first, then match your pump port and couplings to it. For suction duty check the 0.9 bar vacuum rating and keep suction runs short and straight, and do not bend the hose tighter than the bend radius in the table. Dixon also lists made-up A210 assemblies with camlock, Minsup Surelock and Bauer ends (manufacturer-stated); ask us if you want a coupled length instead of a coil.
Related products
Related Dixon hose: Dixon Rubber Air & Water Discharge Hose, Rubber Fire Resistant Anti Static Air & Water Suction & Delivery Hose, Dixon Heavy Duty Grey PVC Suction Hose and Dixon Rubber Petrol & Oil Suction & Delivery Hose.
Resources
