Stahlwille SW730D/10 10-100 N·m 730D Electronic Torque Wrench, 9 x 12 mm holder

The Stahlwille MANOSKOP 730D is an electromechanical torque wrench that combines cut-out and indicating in one tool, with a mount for interchangeable insert tools and a QuickRelease safety lock. This listing covers four sizes, from size 10 (10 to 100 N·m) to size 65 (65 to 650 N·m) (manufacturer-stated).

The setting is entered on a foil keypad and shown on a large display, in N·m, ft·lb or in·lb. When the preset torque is reached the wrench cuts out with a tactile and acoustic signal, and it then shows the torque actually applied. Different tolerance limits can be set for each joint, red and green signals in the display confirm the status of each joint, and up to 7,500 results are stored and can be transferred by USB to a PC. A PIN code protects the presets (manufacturer-stated).

Stahlwille states a deviation of indication of ±2% ±1 digit and a calibration certificate in accordance with DIN EN ISO 6789-2:2017 (manufacturer-stated). The wrench runs on two 1.5 V AA batteries, and insert tools are ordered separately.

Where this product is used

• Tightening joints where the result must be recorded and traced
• Service work and series production with different tolerance limits for each joint
• Maintenance where the operator must see the torque actually applied

Features

• Cut-out and indicating modes, selectable independently (manufacturer-stated)
• Shows the torque actually applied after the wrench cuts out (manufacturer-stated)
• Units of N·m, ft·lb and in·lb (manufacturer-stated)
• Different tolerance limits for each joint, with red and green status in the display (manufacturer-stated)
• Stores 7,500 results and transfers them to a PC by USB (manufacturer-stated)
• PIN code protects the presets; automatic keypad lock (manufacturer-stated)
• Automatic compensation when a changed extension is entered (manufacturer-stated)
• Automatic notification of the next calibration date (manufacturer-stated)
• Power supply of two 1.5 V AA batteries (manufacturer-stated)

Common specifications

Key specifications

Figures are Stahlwille's (manufacturer-stated). A dash means no weight is listed here.

Selecting the right option

Choose the 730D when you need the result recorded or want to see the torque actually applied. If a mechanical click is enough, the Stahlwille 730N clicking torque wrenches, 4 to 650 N·m is the simpler wrench with ±3% deviation of indication. If you also need angle control, see the Stahlwille 714 electronic torque and angle wrenches, 1 to 400 N·m or the Stahlwille 713R SENSOTORK electronic torque and angle wrenches, 3 to 400 N·m. Check or recalibrate the wrench regularly with a torque tester such as the Stahlwille SENSOTORK 7707 W workshop torque testers, 0.4 to 1100 N·m.
