Dixon CODE952050 50 mm x 5 m Code 952 Composite Chemical Medium Duty Hose
Out of stock
This Dixon Code 952 hose is a composite chemical hose with a white composite tube, a grey composite cover with an Armatex abrasion resistant finish, polypropylene film and fabric reinforcement and a stainless steel outer wire (manufacturer-stated). It differs from the Code 951 hose, which has a galvanised steel outer wire.
Dixon rates it at 150 PSI (10 bar) working pressure, 750 PSI (50 bar) burst and 0.9 bar vacuum, for -30°C to 80°C, and says it is constructed in accordance with EN 13765 hose and assembly standards, Type 2 (manufacturer-stated). This listing covers the 50 mm hose as a 5 m cut length and a 40 m length.
Where this product is used
- Suction and discharge of a wide range of chemicals with pumps, process equipment, road tankers and rail tankers (manufacturer-stated).
- Chemical transfer on plant, rail and road tankers, mine sites and chemical manufacturing plants (manufacturer-stated).
- Lines where a stainless steel outer wire is preferred over galvanised steel.
Features
- Stainless steel outer wire and poly-coated inner wire (manufacturer-stated)
- Composite tube (white) and cover (grey) with Armatex abrasion resistant finish (manufacturer-stated)
- Anti-static, ozone, weather, abrasion, chemical and oil resistant (manufacturer-stated)
- Working pressure 150 PSI (10 bar); burst pressure 750 PSI (50 bar); vacuum 0.9 bar (manufacturer-stated)
- Temperature range -30°C to 80°C (manufacturer-stated)
- Constructed in accordance with EN 13765:2018 Type 2 (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Tube | Composite, white |
| Cover | Composite, grey, Armatex abrasion resistant |
| Reinforcement | Polypropylene film and fabric |
| Outer wire | Stainless steel |
| Inner wire | Poly coated |
| Working pressure | 150 PSI (10 bar) |
| Burst pressure | 750 PSI (50 bar) |
| Vacuum | 0.9 bar |
| Temperature range | -30°C to 80°C |
| Hose standard | EN 13765:2018 Type 2 (manufacturer-stated) |
| Size | 50 mm hose ID (2 in) |
Key specifications
| Dixon part number | Pack | Hose ID (mm) | Working PSI (bar) | Burst PSI (bar) | Vacuum (bar) | Bend radius (mm) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|
| CODE952050 | 5 m cut length | 50.8 | 150 (10) | 750 (50) | 0.9 | 150 | 1.56 |
| CODE952050040 | 40 m length | 50.8 | 150 (10) | 750 (50) | 0.9 | 150 | 1.56 |
Figures are from Dixon's composite hose catalogue, which lists the hose as 50.8 mm ID. The 40 m part number (CODE952050040) is not printed in the catalogue; it carries the ratings of the CODE952050 row.
Selecting the right option
Choose Code 952 when the stainless steel outer wire matters for your site or product; choose the Code 951 hose (linked below) when a galvanised steel outer wire is acceptable. Check your chemical against the composite materials and confirm the operating temperature, because the ratings above apply from -30°C to 80°C only. For hose assemblies, Dixon recommends gathering all S.T.A.M.P.E.D. information and proof testing and tagging each assembly (manufacturer-stated).
Related products
Related Dixon hoses: Dixon Code 951 Composite Chemical Medium Duty Suction & Delivery Hose, Dixon Rubber UHMW Polyethylene Suction & Delivery Chemical Hose and Dixon Composite Hydrofrac Heavy Duty Suction & Delivery Hose.
