1/4 in (8 mm) Stainless Steel 3-Way Ball Valve, L-Port | SS3WAY08L

This AAP stainless steel ball valve is a 3-way L-port valve. It is supplied in 8 sizes from 1/4 in (8 mm) to 2 in (50 mm).

A ball valve turns a ball with a hole through it between sealing seats. When the lever or handle is in line with the pipe the hole lines up with the flow and the valve is open, and a quarter turn closes it. AAP notes that the handle sits in line with the port, so it shows the valve position.

AAP gives a maximum working temperature of 180 degrees C and a cold working pressure of 6,895 kPa (68.95 bar), with a body in CF8M, a 316 stainless steel ball and stem, and a PTFE (Teflon) seat (manufacturer-stated). It suits air, water and hot or cold corrosive fluids in harsh environments, per the manufacturer.

An L-port ball connects the common port to either of the other two ports, so it diverts flow from one line to another.

Where this product is used

• Diverting flow between two lines from one supply
• Switching a pump or tank between two branches
• Corrosive fluid, water and air lines
• Process pipework in harsh environments

Features

• 8 sizes from 1/4 in (8 mm) to 2 in (50 mm)
• 3-way L-port ball
• 316 stainless steel ball and stem with a PTFE seat
• Thread to AS 1722.1 (manufacturer-stated)
• Cold working pressure 6,895 kPa (68.95 bar), maximum 180 degrees C (manufacturer-stated)

Key specifications

Options and part numbers

Selecting the right option

Choose the size to match your pipe thread. The L-port ball diverts flow between two lines, so check that the flow pattern suits your pipework. AAP lists brass 3-way valves in L-port and T-port for other duties.
