Beaver g70 load chain kit with grab hooks, 8 / 6
Available
Beaver Grade 70 transport load chain kits are lashing chain with a grab hook fitted at each end, in 6, 7.1 and 8mm chain, in 6 m lengths with regular grab hooks and 9 m lengths with winged grab hooks. Lashing capacities (LC) are 2,300kg to 3,800kg. The chain is manufactured from heat treated carbon steel in accordance with AS/NZS 4344, with a zinc di-chromate (gold) finish.
The chain and fittings are marked Grade 70 with the lashing capacity and chain size, and the kit is supplied in a resealable poly bucket. The chain is primarily used in lashing applications to tie down loads on transport equipment. Use this kit for load restraint only. Some grab hooks, and systems that use them, bend the link of the lashing chain the hook is engaged on. LC is the lashing capacity.
Where this product is used
- Lashing applications to tie down loads on transport equipment
- Load restraint on trucks and trailers, with the chain, binders and anchor points matched to the same LC
Features
- Grade 70 chain with a grab hook at each end
- LC from 2,300kg (6mm) to 3,800kg (8mm)
- Manufactured from heat treated carbon steel to AS/NZS 4344
- Zinc di-chromate (gold) finish
- Marked Grade 70 with LC and chain size
- Supplied in a resealable poly bucket
- Not to be used for lifting purposes
Key specifications
| Specification | Detail |
|---|---|
| Brand | Beaver |
| Product type | G70 Transport Chain |
Choosing the right option
Weights are approximate.
Choose the chain size and LC your load restraint needs, remembering Beaver's 25 percent reduction for systems using grab hooks, and keep every part of the restraint assembly (chain, binder, hooks and anchor points) matched to the same LC. This product is not rated for lifting. Do not use it to lift or suspend loads. For lifting applications use a rated lifting product marked with a working load limit (WLL).
Other Beaver Grade 70 transport restraint items: Beaver G70 Gold Clevis Grab Hook With Wings, Beaver G70 Ratchet Type Loadbinders with Winged Eye Grab Hooks, 6mm to 13mm Chain, Beaver G70 Safety Release (Recoilless) Loadbinders, 7-8mm and 10mm Chain.
| Code | Chain size (mm) | Chain length (m) | Hook type | LC (kg) | Weight each (kg) |
|---|---|---|---|---|---|
| 400903 | 6 | 9 | Winged Grab Hooks | 2,300 | 7.68 |
| 411003 | 7.1 | 9 | Winged Grab Hooks | 3,000 | 10.57 |
| 401003 | 8 | 6 | Regular Grab Hooks | 3,800 | 9.34 |
| 145128 | 8 | 9 | Winged Grab Hooks | 3,800 | 13.63 |
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Beaver Grade 70 Transport Load Chain Kit With Grab Hooks: 8 / 6
SKU: A0203355 | Model: 401003
Beaver 401003 G70 load chain kit, 8mm x 6 m, regular grab hooks, 3,800kg LC. AS/NZS 4344. Not for lifting.
