Loc-Line magnetic base manifold

Loc-Line 40400 is the 1/4" magnetic base manifold for the 1/4" Loc-Line modular hose system (Lockwood Products, USA). the range pack list is one magnetic base manifold, three 1/4" plugs and one 1/4" barb, with a 25 lb holding force.

It has no hose in the pack. The magnetic base manifold kit (40463) and super kit (40480) both list a magnetic base manifold with the same three 1/4" plugs and 1/4" barb, plus hose segments, valves and nozzles. A Prop 65 warning applies to 40400 (see the specification).

Where this product is used

• Machine tool coolant supply, applying liquid coolant at the point of contact between the cutting tool and the target metal
• Other uses: the electronic, scientific, graphic arts and woodworking industries, and any job needing adjustable directional flow of fluid, air or vacuum, or third arm positioning

Features

• Pack list: (1) Magnetic Base Manifold, (3) 1/4" Plugs, (1) 1/4" Barb
• Holding force 25 lb
• Magnetic manifold on its own, with no hose segments, valves or nozzles in the pack list
• Warning printed against 40400: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Key specifications

Supplied with

• 1 x Magnetic Base Manifold
• 3 x 1/4" Plugs
• 1 x 1/4" Barb

Choosing the right option

Choose 40400 if you already have 1/4" hose and want the magnetic base manifold with plugs and a barb. 25 lb holding force against 40400 only.

Magnetic base manifold kits: 1/4" magnetic base manifold kit (40463), magnetic base manifold super kit (40480).

Other 1/4" manifold parts: 1/4" modular manifold (21199), 1/4" total flow control manifold kit (21198), 1/4" manifold brackets (21195).

Related part: 1/4" male NPT valves (21192, 29452).
