EasyRoll J3 Swivel Plate Castor, Puncture Proof 220 mm | J32A99B200

The EasyRoll J3 series swivel plate castor is fitted with a puncture proof wheel and is available in 220 and 265 mm wheel diameters. Load capacity is 100 kg to 125 kg per castor depending on the wheel size. The top plate is 115 x 100 mm with hole centres of 76-92 x 73-64 mm.

They suit general and stock picking trolleys; dollies and stillages; catering and industrial laundry equipment. They have ball bearing wheels and a welded steel fork with a fully hardened double headset bearing.

Where this product is used

• General and stock picking trolleys
• Dollies and stillages
• Catering and industrial laundry equipment

Features

• Puncture proof wheel in 220 and 265 mm
• Load capacity 100 kg to 125 kg per castor
• Rugged welded steel construction with a fully hardened double headset bearing
• Ball bearing wheels
• Puncture proof, flat free wheel

Key specifications

Options and part numbers

Selecting the right option

A swivel castor turns to follow the direction of travel and a fixed castor rolls in a straight line, so many trolleys use fixed castors at one end and swivel castors at the other. Load capacity is shown per castor, on an average floor at speeds up to 4 km/h (manufacturer-stated). The capacity of a trolley is not the sum of its castors: for a four wheel trolley EHI recommends each castor is rated for at least 35 percent of the total load, which is the weight of the trolley plus what it carries. If you are unsure which castor suits your application, contact AIMS with the load, the floor type and how the equipment is used.
