Description
Description
2 Flute Slot Drill - R30 N - Short - Tecline
- Suitable for materials up to 1600 N/mm2
- TiAlN for longer tool life
Specifications
Specifications
Specifications
- Designation: N
- Material: VHM
- Finish: TiAlN
- Shank Form: HA
- Helix Angle: R30
- Point Tolerance: h10
- Shank Tolerance: h6
- Point Form: Square End
- Type: N (finishing)
- Standard: DIN6527K
- Rake Angle: 12
Applications
Applications
Applications
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)-125HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)-190HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)-250HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)-270HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)-300HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements-180HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements-275HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements-300HB
- Optimal for Steel - High alloy, cast & tool-200HB
- Optimal for Steel - Corrosion resistant & cast - Ferritic / Martensitic-200HB
- Optimal for Steel - Corrosion resistant & cast - Martensitic-240HB
- Optimal for Stainless Steel - Austenitic-180HBOptimal for Stainless Steel - Duplex-250HB
- Optimal for Stainless Steel - Precipitation Hardening-250HB
- Optimal for Cast Iron, Grey (GG) - Ferritic / Pearlitic-180HB
- Optimal for Cast Iron, Grey (GG) - Pearlitic-260HB
- Optimal for Cast Iron, Nodular (GGG) - Ferritic-160HB
- Optimal for Cast Iron, Nodular (GGG) - Pearlitic-250HB
- Optimal for Cast Iron, Malleable - Ferritic-130HB
- Optimal for Cast Iron, Malleable - Pearlitic-230HB
Features & Benefits
Features & Benefits
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
E502 Endmill Sutton
E502 Endmill Sutton
SKU: A0130358
Type: Slot Drill Tecline
- Wide Range
- Reliable Services
- Proven Trust
Available
The E502 Endmill Sutton by Sutton Tools is a Slot Drill Tecline with TiAlN finish for longer tool life. It provides suitability for materials up to 1600 N/mm2 and is suitable for Steel - Non-alloy, cast & free cutting (~ 0.15 %C).
- FREE SHIPPING OVER $299*
- RETURN AND EXCHANGE POLICY
Resources
Couldn't load pickup availability
Description
Description
2 Flute Slot Drill - R30 N - Short - Tecline
- Suitable for materials up to 1600 N/mm2
- TiAlN for longer tool life
Specifications
Specifications
Specifications
- Designation: N
- Material: VHM
- Finish: TiAlN
- Shank Form: HA
- Helix Angle: R30
- Point Tolerance: h10
- Shank Tolerance: h6
- Point Form: Square End
- Type: N (finishing)
- Standard: DIN6527K
- Rake Angle: 12
Applications
Applications
Applications
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)-125HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)-190HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)-250HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)-270HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)-300HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements-180HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements-275HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements-300HB
- Optimal for Steel - High alloy, cast & tool-200HB
- Optimal for Steel - Corrosion resistant & cast - Ferritic / Martensitic-200HB
- Optimal for Steel - Corrosion resistant & cast - Martensitic-240HB
- Optimal for Stainless Steel - Austenitic-180HBOptimal for Stainless Steel - Duplex-250HB
- Optimal for Stainless Steel - Precipitation Hardening-250HB
- Optimal for Cast Iron, Grey (GG) - Ferritic / Pearlitic-180HB
- Optimal for Cast Iron, Grey (GG) - Pearlitic-260HB
- Optimal for Cast Iron, Nodular (GGG) - Ferritic-160HB
- Optimal for Cast Iron, Nodular (GGG) - Pearlitic-250HB
- Optimal for Cast Iron, Malleable - Ferritic-130HB
- Optimal for Cast Iron, Malleable - Pearlitic-230HB
Features & Benefits
Features & Benefits
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
E502 Endmill Sutton
Customer Service
Mon-Fri, 08:00-05:00pm
Call Us
(02) 9773-0122
Talk to a Sales Engineer
sales@aimsindustrial.com.au
Warehouse Address
Milperra NSW 2214, Australia
Your cart
(0)
Your cart is currently empty.
Not sure where to start? Try these collections:
Order note
Estimate Shipping
Product Comparison
| Description |
| Price |
| Vendor |
| Type |
| Product variants |
|
| The E502 Endmill Sutton by Sutton Tools is a Slot Drill Tecline with TiAlN finish for longer tool life. It provides suitability for materials up to 1600 N/mm2 and is suitable for Steel - Non-alloy, cast & free cutting (~ 0.15 %C). |
Regular price
$54.74
Sale price
$54.74
Regular price
Unit price
/per
| Sutton Tools | Slot Drill Tecline |
Cutting Tip (mm)
2,3
Overall Length (mm)
50
|
Choose your option
E502 Endmill Sutton
E502 Endmill Sutton
SKU: A0130358
Type: Slot Drill Tecline
Hurry up, only 5 items left in stock.
The E502 Endmill Sutton by Sutton Tools is a Slot Drill Tecline with TiAlN finish for longer tool life. It provides suitability for materials up to 1600 N/mm2 and is suitable for Steel - Non-alloy, cast & free cutting (~ 0.15 %C).
